Qlima D620 User Manual

43
4
TECHNICAL SPECIFICATIONS
Model D620 D625
Power consumption (nom / max) kW 0.26-0.32 0.30-0.37
Power supply V / Hz / Ph 220-240 / ~ 50 / 1 220-240 / ~ 50 / 1
Current (nom.) A 1.56 1.66
Dehumidifying capacity (moisture
removal) at 30ºC, 80%RH
L / 24h 20 25
Dehumidifying capacity (moisture
removal) at 27ºC, 60%RH
L / 24h 12 14
Capacity water container L 4 4
Air flow (nom.)* m3/h 160 173
For rooms up to* m3 100 - 130 140 - 165
Operating range °C 5 - 35 5 - 35
Automatic defrost Yes Yes
Hygrostat Yes Yes
Compressor type Reciprocating Reciprocating
Refrigerant type / charge r / gr R134a / 170 R134a / 184
Pressure suction / discharge (max.) MPa 2.5 / 9.5 (15.3) 3.3 / 11.7 (15.8)
Dimensions (w x d x h ) mm 346 × 253 × 590 346 × 253 × 590
Net weight kg 13.2 14.0
Gross weight kg 14.4 15.2
Sound pressure level * dB(A) 39 39
Unit Protection IP IPX4 IPX4
Fuse rating 250V, 10A 250V, 10A
* To be used as indication
Subject to change without prior notice.

Qlima D620 Specifications

General

Power	340 W
Best uses	Bedroom
Placement	Floor
Air filter	Yes
Noise level	34 dB
Product color	White
Housing material	Plastic
Number of speeds	3
Water tank capacity	4 L
Dehumidifying capacity (max)	20 l/24h
Suitable for room volume up to	130 m³
International Protection (IP) code	IPX4
Operating temperature (T-T)	0 - 35 °C
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Package depth	307 mm
Package width	398 mm
Package height	631 mm
Package weight	15000 g

Weight and Dimensions

Depth	253 mm
Width	346 mm
Height	590 mm
Weight	14000 g
