4 – Managing Switches
Using the Switch Data Window
59264-02 A 4-7
A
Merge Auto Save If enabled, any zoning updates from the fabric will be
saved in permanent (non-volatile) memory as well as
temporary memory. If disabled, any zoning updates
from the fabric will be saved only in temporary memory
and will be lost after a switch reset.
Zoning Default Visibility N/A - does not apply to this switch
Default Zone Disables communication between ports and devices
not defined in the active zone set, or when there is no
active zone set.
Discard Inactive Automatically removes the previously active zone set
when a zone set is activated on a switch.
Implicit Hard Zoning Introduces hardware enforcement of zoning regardless
of type. All zones and all supported zone member
types will have hardware enforcement.
Security Auto Save N/A - does not apply to this switch
Security Fabric Binding Enable N/A - does not apply to this switch
Advanced Group
R_A_TOV Resource allocation timeout value
E_D_TOV Error detect timeout value
Number of Donor Groups Total number of donor port groups. A donor group is a
set of ports on a switch that can donate buffer credits to
each other.
Inactivity Timeout Number of minutes the switch waits before terminating
an idle command line interface session. Zero (0) dis-
ables the time out threshold.
In-band Enabled In-band management status. Permits (True) or pre-
vents (False) a switch from being managed over an
ISL.
Principal Switch If there is a domain ID conflict in the fabric, the switch
with the highest principal priority, or the principal
switch, will reassign any domain ID conflicts and estab-
lish the fabric.
Table 4-1. Switch Data Window Entries (Continued)
Entry Description
