To check for the latest available version, click Start.
The wizard downloads the latest available version, and then the NAS restarts after the download
is complete. If a newer version is not available, the wizard automatically displays the Smart
Installation Guide.
To install the out-of-the-box version, click Skip.
10. Click Start Smart Installation Guide.
11. Specify the following information.
NAS name: Specify a name with 1 to 14 characters. The name supports letters (A to Z, a to z),
numbers (0 to 9), and hyphens (-), but cannot end with a hyphen.
Password: Specify an administrator password with 1 to 64 characters. The password supports all
ASCII characters.
12. Click Next.
13. Specify the time zone, date, and time.
Tip
QNAP recommends connecting to an NTP server to ensure that the NAS follows the
Coordinated Universal Time (UTC) standard.
14. Click Next.
15. Select Obtain an IP address automatically (DHCP).
16. Click Next.
17. Select the types of devices that you will use to access shared folders on the NAS.
18. Click Next.
19. Select Configure disks later.
Note
For details on configuring disks, see the Storage Manager section of the QTS User Guide.
20. Configure the disk settings.
a. Select a volume type.
b. Select the disks that you want to use to create a RAID group.
c. Optional: Select a RAID type.
Note
The Smart Installation Guide automatically selects the optimal RAID type based on the
number of the selected disks.
d. Optional: Select Encrypted Disk Volume and Bad Block Scan.
21. Click Next.
22. Select No.
TS-x28A User Guide
Installation and Configuration 13

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-128A and is the answer not in the manual?

QNAP TS-128A Specifications

General IconGeneral
Bad block scanYes
Storage drive size- \
Storage drive capacity0 GB
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4
Storage drive interface-
Storage drives installedNo
Storage drive sizes supported3.5 \
Supported storage drive typesHDD
Total installed storage capacity0 TB
Number of storage drives installed0
Number of storage drives supported1
Supported storage drive interfacesSerial ATA, Serial ATA II, Serial ATA III
Processor cores4
Processor familyRealtek
Processor frequency1.4 GHz
Processor architectureARM Cortex-A53
Flash memory4000 MB
Internal memory1 GB
Internal memory typeDDR4
Ethernet LAN data rates1000 Mbit/s
USB 2.0 ports quantity2
Chassis typeMini Tower
Cooling typeActive
Fan diameter40 mm
Product colorWhite
LED indicatorsNetwork, Status, System
Number of fans1 fan(s)
TypeNAS
Device classHome & Home Office
Backup featuresCloud, iSCSI LUN
Browser supportedApple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH
Operating system version4.3.4
Operating system installedQNAP Turbo System
Mac operating systems supportedMac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supportedWindows 10, Windows 7, Windows 8
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply locationExternal
Power consumption (typical)7.06 W
Power consumption (HDD standby)2.9 W
Power supply unit (PSU) capacity36 W
Cables includedAC, LAN (RJ-45)
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Weight and Dimensions IconWeight and Dimensions
Depth125 mm
Width60 mm
Height187.7 mm
Weight560 g
Package weight1740 g
