10. Click Start Smart Installation Guide.
11. Specify the following information.
NAS name: Specify a name with 1 to 14 characters. The name supports letters (A to Z, a to z),
numbers (0 to 9), and hyphens (-), but cannot end with a hyphen.
Password: Specify an administrator password with 1 to 64 characters. The password supports all
ASCII characters.
12. Click Next.
13. Specify the time zone, date, and time.
Tip
QNAP recommends connecting to an NTP server to ensure that the NAS follows the
Coordinated Universal Time (UTC) standard.
14. Click Next.
15. Select Obtain an IP address automatically (DHCP).
16. Click Next.
17. Select the types of devices that you will use to access shared folders on the NAS.
18. Click Next.
19. Configure the disk settings.
a. Select a volume type.
b. Select the disks that you want to use to create a RAID group.
c. Optional: Select a RAID type.
Note
The Smart Installation Guide automatically selects the optimal RAID type based on the
number of the selected disks.
d. Optional: Select Encrypted Disk Volume and Bad Block Scan.
20. Click Next.
21. Review the settings.
22. Click Apply.
A confirmation message appears.
Warning
Clicking Confirm deletes all data on the drive before installing QTS.
23. Click Confirm.
QTS is installed.
TS-1635AX User Guide
Installation and Configuration 35

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-1635AX and is the answer not in the manual?

QNAP TS-1635AX Specifications

General IconGeneral
Internal memory4 GB
Internal memory typeDDR4
Maximum RAM supported16 GB
RAID levels0, 1, 5, 6, 10, 60, JBOD
RAID supportYes
Storage drive size- \
Storage drive capacity0 GB
Supported file systemsFAT32, HFS+, exFAT, ext3, ext4
Storage drive interface-
Storage drives installedNo
Number of M.2 (M & B) slots2
Storage drive sizes supported2.5, 3.5 \
Supported storage drive typesHDD & SSD
Total installed storage capacity0 TB
Number of storage drives installed16
Supported storage drive interfacesSerial ATA, Serial ATA II, Serial ATA III
Ethernet LAN data rates10, 100, 1000, 10000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
Fiber optic connectorSFP+
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Processor cores4
Processor familyMarvell
Processor frequency1.6 GHz
Processor architectureARM Cortex-A7
PCI Express slots version3.0
Chassis typeDesktop
Cooling typeActive
Display typeLCD
Fan diameter92 mm
Product colorBlack
Fan diameter 260 mm
Number of fans4 fan(s)
Cable lock slot typeKensington
Number of built-in speakers1
TypeNAS
Noise level23 dB
Device classSmall & Medium Business
Backup featuresCloud, iSCSI LUN
Browser supportedApple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms256-bit AES
Fan voltage12 V
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply unit (PSU) capacity250 W
Storage temperature (T-T)5 - 95 °C
Operating temperature (T-T)0 - 40 °C
Operating system version4.3.4
Operating system installedQNAP Turbo System
Cables includedAC, LAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth319.8 mm
Width369.89 mm
Height303.84 mm
