QNAP TS-219P User Manual

Or
ange The NAS is connected to the network
LAN Orange
Flashes
orange
The NAS is being accessed from the network
Green
The 10GbE network expansion card is
installed
10 GbE
1
Green
Off No 10GbE network expansion card is installed
Flashes red
The disk data is being accessed and a
read/write error occurs during the process
Red A hard disk drive read/write error occurs
Flashes green The disk data is being accessed
HDD
Red/
Green
Green The hard disk drive can be accessed
Flashes blue
every 0.5 sec
1. A USB device (connected to the front USB
port) is being detected
2. A USB device (connected to the front USB
port) is being removed from the NAS
3. The USB device (connected to the front
USB port of the NAS) is being accessed
4. The data is being copied to or from the
external USB or eSATA device
Blue
A front USB device is detected (after the
device is mounted)
USB Blue
Off
1. No USB device is detected
2. The NAS has finished copying the data to
or from the USB device connected to the
front USB port
Flashes The eSATA device is being accessed
eSATA
2
Orange
Off No eSATA device can be detected
1
The 10 GbE network expansion function is only supported by the TS-879 Pro, TS-1079 Pro,
TS-879U-RP, TS-1279U-RP, TS-EC879U-RP, and TS-EC1279U-RP.
2
TS-210, TS-219, TS-439U-SP/RP, TS-809 Pro, TS-809U-RP, TS-212 do not support eSATA port.
22

QNAP TS-219P Specifications

General

Processor family	Marvell
Processor frequency	1.2 GHz
Number of processors installed	1
Storage drive size	3.5 \
Storage drive capacity	0 GB
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	2
Flash memory	16 MB
Internal memory	0.5 GB
eSATA	Yes
USB 2.0 ports quantity	3
Dimensions (WxDxH)	102 x 216 x 150 mm
Power requirements	100 - 240 V AC, 50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Chassis type	Tower
Power supply unit (PSU) capacity	60 W

Weight and Dimensions

Weight	1740 g
