The NA
S supports hot-swapping the hard drives when 1 member drive crashes in RAID 1,
1–2 member drives crash in RAID 5 or RAID 6. Follow the steps below to hot-swap the
hard drive when a member drive fails in a RAID configuration.
1. Login the NAS and check the disk volume configuration in “Volume Management”.
2. The volume status should be “in degraded mode”.
3. Prepare a new hard drive to replace the failed one. The capacity of the new hard drive
should be the same as or larger than the failed hard drive.
4. Unplug the failed drive from the NAS. Wait for about 20 seconds or until the server
beeps twice.
5. Remove the failed drive from the drive tray.
6. Install the new hard drive on the drive tray. Insert it to the NAS.
7. The server should beep 1.5 seconds twice.
8. Check the volume status on the web administration page. The volume should be
rebuilding.
Warning: Users are strongly recommended to turn OFF the server before replacing
the hard drive to reduce the risk of electric shock.
40

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-412 and is the answer not in the manual?

QNAP TS-412 Specifications

General IconGeneral
RAID levels0, 1, 5, 6, 10
Storage drive size2.5/3.5 \
Storage drive capacity- GB
Supported file systemsext3, ext4, FAT32, HFS+, NTFS
Storage drive interfaceSerial ATA, Serial ATA II
Total installed storage capacity- TB
Maximum supported storage capacity8 TB
Number of storage drives installed-
Number of storage drives supported4
Flash memory16 MB
Internal memory0.25 GB
Internal memory typeDDR2
Processor model6281
Processor familyMarvell
Processor frequency1.2 GHz
Number of processors installed1
Fan90 mm
Dimensions (WxDxH)180 x 235 x 177 mm
Power requirements100-240V
Networking featuresGigabit Ethernet
Compatible operating systemsWindows 2000; Windows XP; Windows Vista (32/ 64 bit); Windows Windows 7 (32/ 64 bit); Windows Server 2003/2008; Mac OS X; Linux & Unix.
DHCP clientYes
Maximum data transfer rate1000 Mbit/s
Supported network protocolsTCP/IP
Security algorithmsHTTPS, SSH, SSL/TLS
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports2
Chassis typeTower
LED indicatorsHDD, LAN, Power, Y
Number of fans1 fan(s)
Power consumption (sleep)11 W
Power consumption (typical)26 W
Power supply unit (PSU) capacity120 W
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Weight3000 g
