To re ver t to the defaul t pa ssword, use a pin to press the Reset button for three secon ds or until yo u hea r a s hor t beep
Zum Rücksetzen auf das Standardkennwort müssen Sie die Reset-Taste drei Sekunden lang oder bis zur
Ausgabe eines kurzen Signaltons mit einem schmalen spitzen Gegenstand drücken
Pour revenir au mot de passe par défaut, utilisez une pointe pour appuyer sur le bouton initialiser pendant trois
secondes ou jusqu'à ce que vous entendiez un bip court
Per tornare alla password predenita, usare uno spillo per premere il tasto Reset per tre secondi o no a che
non si sente il segnale acustico
Para restaurar la contraseña predeterminada, utilice un objeto puntiagudo para pulsar el bon Restablecer
durante tres segundos o hasta que escuche un pitido corto
Om terug te keren naar het oude wachtwoord, gebruikt u een pennetje om de Reset-knop drie seconden in te
drukken of tot u een korte pieptoon hoort
För att återställa standardlösenordet , använd en nål för att trycka in återställningsknappen i tre sekunder eller
tills du hör ett kort pip
Palataksesi oletussalasanaan, paina neulalla nollauspainiketta kolme sekuntia, kunnes kuulet lyhyen merkkiäänen
For at gendanne til standardadgangskoden, skal du bruge en clips til at trykke nulstillingsknappen i tre
sekunder eller indtil du hører et kort bip
For å gå tilbake til standardpassordet kan du bruke en nål til å trykke inne Reset-knappen i tre sekunder eller til
du hører et kort pip
Para reverter para a senha padrão, utilize um pino para pressionar o botão de Reset por ts segundos ou até
que você ouça um bipe curto
Чтобы восстановить пароль по умолчанию, булавкой держите нажатой кнопку сброса три секунды или
до подачи короткого звукового сигнала
恢復預設密碼的方法:用迴紋針尖壓著「重設」鈕三秒鐘,直到聽見短促嗶聲為止
欲恢复到默认密码,请用针状物抵按 Reset 3 秒或直至听见短促“哔”声
既定のパスワードに戻すには、ピンを利用してリセットボタンを 3 秒間 ( あるいは、ビープ音が短く鳴るまで ) 押します
󸞆󹙎 󹞚󹕖󹗞󺾎󹆲 󸵮󸴢󹌂󹅺󹏊 Reset( 󹌂󹪡 ) 󹗚󺰒󺂚 󺺖󺂒󹆲 3 󺙞󸕚 󸽦󸯪 󺌽󺂖 󸘓󸘶󺂢󺃊 󺀎󹌊 󸺢󸞢󺌖 󸭚󹋊󸘶 󺃞󺂒󹏊 󸵿󸰞󸰺
ากต้องการกับังรั่าค่าเริ่มต้ ้้เ็มกด่มรเ็ตเ็เวา  วิา รือกว่าคด้ิเงัาเตือั้ 
Varsayılan şifreye dönmek amacıyla, Sıfırla düğmesine üç saniye boyunca veya kısa bir sesli uyarı duyana kadar
basmak için bir iğne kullanın
Az alapértelmezett jelszó visszaállításához nyomja meg a Reset gombot a tűvel három másodpercig vagy amíg
egy rövid hangjelzést nem hall
Chcete-li obnovit původní heslo, pomocí tenkého a špičatého edmětu stiskněte a podržte resetovací tlačítko
tři sekundy nebo do zaznění krátkého pípnutí
Aby przywrócić hasło domyślne, należy za pomocą szpilki wcisnąć przycisk Reset i przytrzymać go przez trzy
sekundy, aż do usłyszenia krótkiego sygnału
Reset
ﺼﻗ ﻔﺻ تﻮﺻ ﻊﻤﺴﺗ ﻰﺘﺣ وأ
ٍ
ناﻮ ثﻼ ةﺪ
(ﻂﺒﻀﻟا ةدﺎﻋإ )
رز ﲆﻋ ﻂﻐﻀﻠ
ً
ﻮﺑد مﺪﺨﺘﺳا :ﺔﻴﺿاﱰﻓا روﺮﳌا ﺔﻤﻠﻛ ةدﺎﻌﺘﺳ
Reset
Reset

Other manuals for QNAP TS-453BT3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-453BT3 and is the answer not in the manual?

QNAP TS-453BT3 Specifications

General IconGeneral
SteppingB1
Tjunction105 °C
Processor codeSR2Z9
Processor cache2 MB
Processor cores4
Processor modelJ3455
System bus rate- GT/s
Processor familyIntel® Celeron®
Processor socketBGA 1296
Processor codenameApollo Lake
Processor frequency1.5 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor package size24 x 31 mm
CPU configuration (max)1
Conflict-Free processorYes
PCI Express slots version2.0
Processor boost frequency2.3 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x2+2x1, 4x1
Thermal Design Power (TDP)10 W
On-board graphics card modelIntel® HD Graphics 500
Maximum internal memory supported by processor8 GB
Memory slots2 x SO-DIMM
Internal memory typeDDR3L
RAID levels0, 1, 5, 6, 10
Storage drive size- \
Storage drive capacity0 GB
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4
Storage drive interface-
Number of M.2 (M & B) slots2
Storage drive sizes supported2.5, 3.5 \
Supported storage drive typesHDD & SSD
Total installed storage capacity0 TB
Number of storage drives installed0
Supported storage drive interfacesSerial ATA, Serial ATA II, Serial ATA III
Ethernet LAN data rates1000, 10000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
HDMI version1.4b
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity5
Cables includedAC, LAN (RJ-45)
Number of screws28
Chassis typeTower
Cooling typeActive
Display typeOLED
Fan diameter120 mm
Product colorBlack
LED indicatorsHDD, LAN, Status, USB
Number of fans1 fan(s)
Cable lock slot typeKensington
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply locationExternal
Power consumption (typical)38.101 W
Power supply unit (PSU) capacity120 W
TypeNAS
Device classHome & Home Office
Share folderCIFS/SMB, FTP, WebDAV
Backup featuresCloud, iSCSI LUN
Browser supportedApple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Operating system version5.0.0
Operating system installedQNAP Turbo System
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supportedWindows 10, Windows 7, Windows 8
Number of execution units12
Maximum number of PCI Express lanes6
Memory types supported by processorDDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM
Memory channels supported by processorDual
Intel Identity Protection Technology version1.00
Intel Small Business Advantage (SBA) version0.00
On-board graphics card base frequency250 MHz
On-board graphics card burst frequency750 MHz
Processor ARK ID95594
Harmonized System (HS) code84714100
Weight and Dimensions IconWeight and Dimensions
Depth226 mm
Width170 mm
Height168 mm
Weight2510 g
Package weight4050 g
