QNAP TS-453BT3 Quick Installation Guide

QNAP TS-453BT3
16 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #3 background imageLoading...
Page #3 background image
SSD / HDD
http://www.qnap.com/compatibility
sv
nl
hu
cs
cn
pl
ar
tr
th
ko
ru
ja
zh
en
pt
no
da
de
fr
it
es
fi
All the drive data will be cleared upon SSD / HDD initialization
Alle Laufwerksdaten werden bei SSD/HDD-Initialisierung gelöscht
To ute s le s do nn ée s pr és en tes s ur l es d is qu es s er on t ef fa cé es l or s de l 'i ni ti al is at io n de s SS D/ HD D
Tutti i dati presenti verranno cancellati durante l'inizializzazione degli SSD / HDD
Tod os lo s datos del disco serán borrados con la inicial iza ción del S SD / HDD
Alle gegevens worden gewist tijdens de initialisatie van de SSD / HDD's
All data kommer att raderas när SSD / HDD initieras
SSD / HDD alustaminen poistaa kaikki tiedostot
Alle data på drevet vil blive ryddet efter initialisering af SSD / HDD
All data vil bli slettet når SSD / HDD er initialisert
Tod os os dado s do SSD / HD D s erão apagados com a inicialização do SSD / HDD
После инициализации SSD/HDD все данные на нем будут удалены
硬碟初始化時,所有資料皆會被清除
所有 SSD / HDD 上的数据都将会被清除
SSD/HDD を初期化すると、すべてのデータが消去されます
SSD / HDD 󹋒 󺙞󸞆󺾪 󹰲󺧺󹏊 󸸲󹃒󺃊󹝢󺂮 󹏾󸸶 󸳆󺃊󺪆󸕖 󹫦󹰺󸵿󸰞󸰺
้อมูดรูกบออก เมื่อมการตั้งค่าเริ่มต้
Kurulum başladığında SSD / HDD disk üzerinde ki tüm veri silinecektir
Minden korábbi adat törlődik az SSD / HDD-ről az első rendszerindítás során
echna data na SSD / HDD budou smazána v důsledku inicializace
Podczas instalacji wszystkie dane na dyskach SSD / HDD zostaną usunięte
ﺔﺌﻴﻬﺗ ﺪﻨﻋ صاﺮﻗﻷا كﺮﺤﻣ تﺎﻧﺎﻴﺑ ﻞﻛ ﺢﺴﻣ ﻢﺘﻳ(ﺔﺒﻠﺼﻟا ﺔﻟﺎﺤﻟا صﺮﻗ)HDD(ﺔﺒﻠﺼﻟا صاﺮﻗﻷا كﺮﺤﻣ)SSD/

Other manuals for QNAP TS-453BT3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-453BT3 and is the answer not in the manual?

QNAP TS-453BT3 Specifications

General IconGeneral
SteppingB1
Tjunction105 °C
Processor codeSR2Z9
Processor cache2 MB
Processor cores4
Processor modelJ3455
System bus rate- GT/s
Processor familyIntel® Celeron®
Processor socketBGA 1296
Processor codenameApollo Lake
Processor frequency1.5 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor package size24 x 31 mm
CPU configuration (max)1
Conflict-Free processorYes
PCI Express slots version2.0
Processor boost frequency2.3 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x2+2x1, 4x1
Thermal Design Power (TDP)10 W
On-board graphics card modelIntel® HD Graphics 500
Maximum internal memory supported by processor8 GB
Memory slots2 x SO-DIMM
Internal memory typeDDR3L
RAID levels0, 1, 5, 6, 10
Storage drive size- \
Storage drive capacity0 GB
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4
Storage drive interface-
Number of M.2 (M & B) slots2
Storage drive sizes supported2.5, 3.5 \
Supported storage drive typesHDD & SSD
Total installed storage capacity0 TB
Number of storage drives installed0
Supported storage drive interfacesSerial ATA, Serial ATA II, Serial ATA III
Ethernet LAN data rates1000, 10000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
HDMI version1.4b
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity5
Cables includedAC, LAN (RJ-45)
Number of screws28
Chassis typeTower
Cooling typeActive
Display typeOLED
Fan diameter120 mm
Product colorBlack
LED indicatorsHDD, LAN, Status, USB
Number of fans1 fan(s)
Cable lock slot typeKensington
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply locationExternal
Power consumption (typical)38.101 W
Power supply unit (PSU) capacity120 W
TypeNAS
Device classHome & Home Office
Share folderCIFS/SMB, FTP, WebDAV
Backup featuresCloud, iSCSI LUN
Browser supportedApple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Operating system version5.0.0
Operating system installedQNAP Turbo System
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supportedWindows 10, Windows 7, Windows 8
Number of execution units12
Maximum number of PCI Express lanes6
Memory types supported by processorDDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM
Memory channels supported by processorDual
Intel Identity Protection Technology version1.00
Intel Small Business Advantage (SBA) version0.00
On-board graphics card base frequency250 MHz
On-board graphics card burst frequency750 MHz
Processor ARK ID95594
Harmonized System (HS) code84714100
Weight and Dimensions IconWeight and Dimensions
Depth226 mm
Width170 mm
Height168 mm
Weight2510 g
Package weight4050 g
