Cursor blink
OFF
Two different cursor styles are possible. You can select your favourite, here. The two possible
values are an underline cursor (the default), and a blinking cursor (the display alternates between
the edited character, and a solid white block).
When set to ON, the cursor style is Blink. When OFF, the cursor style is Underline (default).
Note that this setting only affects the cursor that is shown during menu system editing. In normal
operating mode, the underline cursor is always used for tuning rate indication, regardless of the
Cursor style setting.
S-meter
OFF
An S-meter is shown in the top right of the display, if this parameter is set to ON. The S-meter is
not yet available as of firmware 1_00_009.
S-meter step
100
This NUMBER parameter effectively defines the sensitivity of the S-meter in legacy QCX-series
transceivers. When the S-meter is implemented in the QMX firmware, this parameter will become
obsolete. It can be ignored for now.
Custom splash
NO
You can use this configuration to display your own customized “Splash” screen on powering up
the QMX. Ordinarily when you power up the QMX it will show this screen:
QMX 1_00_009
QRP Labs, 2023
It shows the firmware version number (1.00_009 in this example). When you set the “Custom
splsh” configuration parameter to YES, the contents of message memories 11 and 12 are
displayed on the top and bottom rows respectively. You would then not normally use these
QMX operang manual; rmware 1_00_012 38
