7
CX 168 / CX 108V
Replacement Parts
CX168 CHASSIS ASSEMBLY
CX168 CHASSIS ASSEMBLY
Part Number Description Reference
Part Number Description Reference
CH-000112-00 SHIELD, LINE FILTER, PLX3002
SC-060042-PP PHILLIPS, PANHEAD SEMS
CH-000118-00 RACK EAR, FRONT, CX902
INTERNAL TOOTH, #6-32,
CH-000159-00 CHASSIS, MAIN, , CX168
0.25" L, BLK, ZINC
CH-000188-00 BRACKET, OUTPUT, CX168
SC-060060-PS PHILLIPS, SEMS EXTERNAL
CO-000169-00 JACK, IEC, 3 POS, FEMALE
TOOTH, #6-32, 0.375" L, ZINC
CO-000199-00 JACK, EURO POWER, 8 POS,
SC-061081-PP PHILLIPS, PANHEAD, #6,
FEMALE, GREEN
0.375" L, ZINC, TYPE B
HW-040001-00 BRACKET, ANGLE, #4-40,
SC-080122-HC HEX, CAP, #8-32, 0.75" L,
0.375" L, ZINC PLATED STEEL
BLACK
HW-060090-SO STANDOFF, 0.250" HEX,
SC-082051-PL PHILLIPS PANHEAD SERATED
#6-32, 0.563" L, ALUMINUM,
BASE, #8, 0.313" L, BLACK
FEMALE
SW-000037-00 AC SW, DPST, 20A, 125VAC,
LB-000053-00 FUSE, REPLACEMENT,
WC-000138-00 CABLE ASSY, AC, 16 AWG,
FRENCH
3 CONDUCTOR, DCA/CX, 5" L
LB-000077-00 WARNING, HIGH ENERGY,
WC-000164-00 CABLE ASSY, OUTPUT
PL 3RU
18 AWG, 8 CONDUCTOR,
LB-000350-00 PRODUCT, FACEPLATE,
CX168, 10" L
CX168
WC-000238-00 RIBBON CABLE ASSY, J103, J104,
LB-000351-00 PRODUCT, MODE SWITCH
28 AWG, 26 CONDUCTOR, J13, J14
REAR, CX168
7" L, AMP CORP ONLY
LB-000409-00
5
AGENCY, 68FA LISTING,
WC-000239-00 RIBBON CABLE ASSY, J504, J704
HORIZONTAL, UL/CUL
28 AWG, 26 CONDUCTOR,
LB-000440-00 LABEL, WIRE CLASS 2
12" L, AMP CORP ONLY
LB-160226-05
6
FUSE, 25A, 125V, UL
WP-000057-00 FAN ASSY, PLC
PL-000066-00 CLIP, CHRISTMAS TREE,
XF-000202-00 CABLE SUPPRESSION,
NYLON, BLACK
100MHZ, 250, CLAMP-ON
PL-000095-00 FAN INTERFACE, PLX 2RU,
POLYPROPYLENE, BLACK
FAN ASSEMBLY
PL-000136-00 KNOB, PLC, PLASTIC, BLACK
PL-000144-00 INSULATOR, FAN DUCT,
Part Number Description Reference
PL2/2A, FISH PAPER
PL-000175-00 ISOLATOR, INPUT, CX168,
CO-000108-00 PLUG, 0.1" CENTERS,
FISH PAPER
2 POS (1X2), FEMALE,
SC-040041-PP PHILLIPS, PANHEAD,
RAMP LOCK 26 AWG
#4-40, 0.25" L, BLACK
MS-000085-00 FAN, 24VDC, 3.15"
SC-040061-PT PHILLIPS, TRUSS, #4-40,
0.375" L, BLACK
