QSC HPR151i - Full Range Amplifier Connections and Controls; Subwoofer Amplifier Connections and Controls

5
Full Range Amplifier Detail
1- Input and Output Connector(s)
2- Gain Control
3- Power, Signal, and Clip LED Indicators
4- Front LED Switch
5- 100 Hz Low-Cut Filter Switch
6- Power Switch
7- Circuit Breaker
8- Serial Number Plate
9- Power Cord Tether Lance
10- IEC Power Inlet
Subwoofer Amplifier Detail
1- Input and Output Connector(s)
2- Gain Control
3- Power, Signal, and Clip LED Indicators
4- Front LED Switch
5- Polarity Switch
6- Power Switch
7- Circuit Breaker
8- Serial Number Plate
9- Power Cord Tether Lance
10- IEC Power Inlet
3
2
6
1
4
5
7
8
9
10
3
2
4
5
8
9
10
6
1
7
