QSC K10.2 Application Guide

K.2 APPLICATION GUIDE— Solo/Duo Musicians 4
The K.2 Series loudspeakers also offer four bands of user-adjustable EQ:
Up to 100 ms of delay.
80, 100, or 125 Hz high-pass filtering for use with a subwoofer.
HIGH
0 to -6 dB 1–10 kHz Shelving
EQ1
0 to -6 dB 50 Hz–20 kHz Q 0.4-4
EQ2
0 to -6 dB 200 Hz–20 kHz Q 0.4-4
LOW
0 to -6 dB 100-500 Hz Shelving
Input A select:
orMIC LINE
Input B select:
orHI-Z LINE
Factory Preset select:
DEFAULT
LIVE
LIVE BRIGHT
DANCE
STAGE MONITOR 1
STAGE MONITOR 2
AC GUIT/VOX
BASS AMP
HAND MIC
HEAD MIC
STUDIO MON
Settings select:
SAVE SCENES
RECALL SCENES
LED
CONTRAST
FACTORY RESET
Delay select:
to0 ms 100 ms
in 0.5 ms increments from 0 to 10;
in 1 ms increments from 10 to 100
High
0 to -6 dB 1–10 kHz Shelving
EQ1
0 to -6 dB 50 Hz–20 kHz Q 0.4–4
EQ2
0 to -6 dB 200 Hz–20 kHz Q 0.4–4
Low
0 to -6 dB 100–500 Hz Shelving
EQ select: orIN OUT
Sub menu select:
NO SUB
80 HZ
100 HZ
125 HZ

QSC K10.2 Specifications

General

Amplifier class	D
Recommended amplifier power (max)	1800 W
Recommended amplifier power (min)	225 W
Amplifier/receiver input interface type	3.5 mm jack, XLR
Package weight	17600 g
Frequency range	50 - 20000 Hz
RMS rated power	- W
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
AirPlay	No
AC (power) in	Yes
Connectivity technology	Wired
Display	1.75\
Transducer material	Titan
Certification	CE, WEEE, UL, China RoHS, RoHS II, FCC B
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	Universal
Audio output channels	1.0 channels
Multi-Room Streaming (MRS) support	-
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
Speaker interface type	XLR

Weight and Dimensions

Depth	300 mm
Width	320 mm
Height	519 mm
Weight	14500 g
