QSC K10.2 Application Guide

K.2 APPLICATION GUIDE— Solo/Duo Musicians 6
SOLO PERFORMER
COFFEEHOUSE GIG / HOUSE CONCERT
For this gig the performer brings two K8.2 loudspeakers to place on stands as mains to reach the audience. The acoustic
guitar and vocal mic mix on one of the main loudspeakers; its MIX OUT signal feeds the opposite loudspeaker. And then that
loudspeaker’s MIX OUT signal feeds the optional third K8.2, which is the monitor.
K8.2
Preset: LIVE
K8.2
Preset:
STAGE MONITOR 1
K8.2
vocal mic
A IN—MIC
acoustic guitar
B IN—INST
MIX OUT
A IN—LINE
MIX OUT
A IN—LINE
Preset: ACOUSTIC GUITAR / VOX
Optional
TECH REQUIREMENTS:
One vocal mic
One acoustic guitar (direct in)
Mains:
One K8.2 loudspeaker [preset Acoustic Guitar / Vox; no sub]
One K8.2 loudspeaker [preset Live; no sub]
Monitor (optional):
One K8.2 loudspeaker [preset Stage Monitor 1]

QSC K10.2 Specifications

General

Amplifier class	D
Recommended amplifier power (max)	1800 W
Recommended amplifier power (min)	225 W
Amplifier/receiver input interface type	3.5 mm jack, XLR
Package weight	17600 g
Frequency range	50 - 20000 Hz
RMS rated power	- W
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
AirPlay	No
AC (power) in	Yes
Connectivity technology	Wired
Display	1.75\
Transducer material	Titan
Certification	CE, WEEE, UL, China RoHS, RoHS II, FCC B
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	Universal
Audio output channels	1.0 channels
Multi-Room Streaming (MRS) support	-
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
Speaker interface type	XLR

Weight and Dimensions

Depth	300 mm
Width	320 mm
Height	519 mm
Weight	14500 g
