QSC K10.2 Application Guide

K.2 APPLICATION GUIDE— Solo/Duo Musicians 7
DUO: GUITAR, BASS, & VOCALS
This guitar/bass duo both sing. Their system consists of a small digital mixer to combine the two vocal mics plus the guitar and
bass fed through DI boxes. The mixer’s main outputs feed the two K10.2 loudspeakers serving as mains.
Two vocal mics
One acoustic guitar (direct in)
One electric bass (direct in)
Digital mixer
Mains:
Two K10.2 loudspeakers [preset Live; no sub]
TECH REQUIREMENTS:
K10.2
In A: LINE
Preset: LIVE
No sub
K10.2
TouchMix -8
™
L R
L
In A: LINE
Preset: LIVE
No sub
R
Aux Out
Main Out

QSC K10.2 Specifications

General

Amplifier class	D
Recommended amplifier power (max)	1800 W
Recommended amplifier power (min)	225 W
Amplifier/receiver input interface type	3.5 mm jack, XLR
Package weight	17600 g
Frequency range	50 - 20000 Hz
RMS rated power	- W
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
AirPlay	No
AC (power) in	Yes
Connectivity technology	Wired
Display	1.75\
Transducer material	Titan
Certification	CE, WEEE, UL, China RoHS, RoHS II, FCC B
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	Universal
Audio output channels	1.0 channels
Multi-Room Streaming (MRS) support	-
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
Speaker interface type	XLR

Weight and Dimensions

Depth	300 mm
Width	320 mm
Height	519 mm
Weight	14500 g
