QSC K10.2 User Manual

EN
16 (DRAFT 2017/05/02)
TD-000523-00-01-C
SETTINGS Utility Functions
Displays
firmware
version and
other menu
selections
RECALL SCENES
LED
K10.2 1.0.6.2844
SAVE SCENES
CONTRAST
FACTORY RESET
Displays the firmware version number – cannot edit this field. Depending on the
loudspeaker model, K8.2, K10.2, or K12.2 displays next to the firmware version. Use
the Selector knob to select the Utility you want, then press the Enter button.
SAVE
SCENES
SAVE
BACK
USER 1
USER 2
SAVE SCENE TO
USER 3
Used to save the current speaker settings to one of five user presets
RECALL
SCENES
LOAD
BACK
DEFAULT
USER 1
RECALL SCENE
USER 2
Used to recall the factory default setting or one of the saved user scenes
LED
FRONT AND REAR
REAR ONLY
LED
FRONT ONLY
Selects which combination of front and rear LEDs illuminate
CONTRAST
LEVEL 8
CONTRAST
TEST TEXT
Adjusts the contrast of the LCD
FACTORY
RESET
YES
NO
USER PRESETS AND
SETTINGS WILL BE
SET TO DEFAULT
FACTORY RESET
CONTINUE?
Resets all parameters to the factory defaults, clears user presets – no undo.

QSC K10.2 Specifications

General

Amplifier class	D
Recommended amplifier power (max)	1800 W
Recommended amplifier power (min)	225 W
Amplifier/receiver input interface type	3.5 mm jack, XLR
Package weight	17600 g
Frequency range	50 - 20000 Hz
RMS rated power	- W
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
AirPlay	No
AC (power) in	Yes
Connectivity technology	Wired
Display	1.75\
Transducer material	Titan
Certification	CE, WEEE, UL, China RoHS, RoHS II, FCC B
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	Universal
Audio output channels	1.0 channels
Multi-Room Streaming (MRS) support	-
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
Speaker interface type	XLR

Weight and Dimensions

Depth	300 mm
Width	320 mm
Height	519 mm
Weight	14500 g
