QSC KSub - FG-003304-01 (120 V) or FG-003324-01 (230 V), K12

59
TD-000487-00
K Series Service Manual
Part Number Description Qty. Reference Comment
MS-000480-00 FELT PAD, POLE MOUNT, K-SERIES, , 6
MS-000496-00 SPACER, LED, , , 1
MS-000543-00 GASKET, PE600MM X 10MM X 1.0MM THK, , , 2
MS-000593-00 STRIP GASKET, , 5X500, EVA, , 0
MS-000604-00 GASKET, STRIP, K-SERIES, , 2
NW-000161-00 NUT, HEX FLG SERR, M5, , STL, CLR, ZINC CR3, 20
NW-000168-00 WSHR, RTNR, M8, , STL, CLR, ZINC CR3, 2
NW-000208-00 NUT, HEX, M8, , , BLK OXIDE, , 2
NW-000209-00 NUT, HEX, M14, , STL, BLK OXIDE, , 2
PL-000062-GP GASKET, 1000X10X2MM, EVA B, , , 1
PL-000593-01 FOOT, ROUND, K10, , BLK, 2
PL-000598-01 FOOT, REAR, K10, , BLK, 1
PL-000601-01
PLATE, POLE CUP, DUAL ANGLE, K10, , BLK, 1 Use pole cup assembly,
SG-000562-TS
PL-000603-01 POLE CUP, SELECTOR, ANGLE, K-SERIES, , BLK, 1
PL-000604-01 POLE CUP, RETAINER, SELECTOR, K-SERIES, , BLK, 1
PL-000607-01 FLARE, PORT, RIGHT, K10, , BLK, 1
PL-000622-01 PLUG, HORN, K10, , BLK, 4
PL-000624-01 FLARE, PORT, LEFT, , BLK, K10 1
PL-000658-01 LOGO, K8/K10, , , BLK, 1
PL-000677-01 FOOT, LONG, BTM, K10, , BLK, 1
PL-000679-01 FOOT, LONG, TOP, K10, , BLK, 1
PL-000856-01 GASKET, BELT, BAFFLE/BUCKET, K10, , BLK, 1
QD-000312-GP LED, 3MM, BLUE SP, SLR343BB T 225419 ROHM, , , 1
SB-000074-01 BUCKET, , K10, , BLK, 1 Not available
SB-000078-01
BAFFLE, , K10, , BLK, 1 Use bafe assembly,
SB-000156-TS
SC-000097-GP SCR, PHH, PNH, , , , , M5, 35 L, STL, BLK, ZINC CR3, 3
SC-000288-00 SCR, PHH, PHN, MACH, , , , M5, 20 L, STL CLASS 4.6, BLK, ZINC CR3, 18
SC-000300-00 SCR, PHH, PNH, MACH, , , , M5, 17 L, STL, BLK, ZINC CR3, 7
SC-000302-00 SCR, PHH, PNH, MACH, , , , M6, 20 L, STL, BLK, ZINC CR3, 4
SC-000303-00 SCR, PHH, PNH, TPG, PLASTITE, , , , M4, 12 L, STL, BLK, ZINC CR3, 8
SC-000304-00 SCR, PHH, PNH, TPG, PLASTITE, , , , M4, 18 L, STL, BLK, ZINC CR3, 8
SC-000305-00 SCR, PHH, PNH, TPG, PLASTITE, , , , M5, 20 L, STL, BLK, ZINC CR3, 10
SC-000306-00 SCR, PHH, PNH, TPG, PLASTITE, , , , M5, 25 L, STL, BLK, ZINC CR3, 11
SP-000181-00 WOOFER, 10", PAPER, FERRITE, , K10 1
SP-000184-00 COMPRESSION DRIVER, , , 1.75", PETP, NEODYMIUM, , K/KW SERIES 1 Diaphragm available,
SR-000145-00
WC-000457-00 WIRE HARNESS, , , , K10, , 1
WP-003308-00 CHASSIS ASSY, MAIN, K10, , UNIVERSAL SUPPLY 1
14.5 FG-003304-01 (120V) or FG-003324-01 (230V), K12
Part Number Description Qty. Reference Comment
CO-000436-00 PLUG, EURO, 3 POS, MALE, GRN 1
LB-000749-00 LABEL, GRILLE TAG, , K12, 1
PM-000270-GP POLYBAG MANUAL, 240X360X0.05, , , , 1
PM-000440-00 CARTON, SHIPPING, , K12, , 120V 1
PM-000441-00 INSERT, TOP, , K12, , 120V 1
PM-000442-00 INSERT, BOTTOM, , K12, , 120V 1
