TD-000487-00

K Series Service Manual

Part Number Description Qty. Reference Comment

PM-000444-00 INSERT, TOP, , KSUB, , 120V 1

PM-000445-00 INSERT, BOTTOM, , KSUB, , 120V 1

PM-000449-00 POLYBAG, , , KSUB, 1120X500X.04MM, 1

PM-000491-00 INSERT, , , KSUB, , 1

PM-000516-00 BAG, , POLYPROPYLENE, K-SERIES, 800MM X 160MM, .3MM THK 1

TD-000276-00 HOOKUP DRAWINGS, K-SERIES, 1

TD-000337-00 WARNING SHEET, PWRD AMP/PWRD LOUDSPEAKER, 1

WC-000361-GP POWER CORD, 120V, IEC V-LOCK, 18AWG, 3M, , NEMA 5-15, , 1

WC-000362-GP POWER CORD, 240V, IEC V-LOCK, 0.75MM, 3M, , CEE 7/7, , 1

WP-003306-01 SPEAKER ASSY, , KSUB, BLK, , UNIV SPLY, PWRD 1

14.10 WP-003306-01, KSub speaker assembly

Part Number Description Qty. Reference Comment

CH-000850-01 HANDLE, , BLK, SPEAKERS, 2

CH-000870-00 PLATE, HANDLE BACKING, , K-SERIES, 4

CH-000889-00 POLE MOUNT, THREADED, M20, KSUB, 1

MS-000074-GP ACOUSTIC WOOL, 200X600X30, , , 4

MS-000259-GP CASTER, SWIVEL, 3 INCH, , 4

MS-000593-00 STRIP GASKET, , 5X500, EVA, , 6

MS-000604-00 GASKET, STRIP, K-SERIES, , 1

NW-000171-00 WSHR, SPLKG, M5, , , , , STL, CLR, ZINC CR3, 16

NW-000172-00 WSHR, FLT, M5, , , 18 OD, , STL, CLR, ZINC CR3, 16

PL-000062-GP GASKET, 1000X10X2MM, EVA B, , , 10

PL-000445-GP FEET, HPR SUBS, , RUBBER, , 4

PL-000479-GP LED HOLDER, FOR HPR, , , , 1

PL-000638-01 BAFFLE SIDE/PORT, KSUB, , , , 2

PL-000640-01 HANDLE BACK CUP, KSUB, , , , 2

PL-000659-01 LOGO, K12, , , BLK, 1

QD-000312-GP LED, 3MM, BLUE SP, SLR343BB T 225419 ROHM, , , 1

SB-000089-01 ENCLOSURE, , KSUB, , , 1

SC-000097-GP SCR, PHH, PNH, , , , , M5, 35 L, STL, BLK, ZINC CR3, 4

SC-000252-00 SCR, PHH, PNH, WOOD, , , , M5, 12 L, STL, BLK, ZINC CR3, 4

SC-000253-00 SCR, PHH, PNH, WOOD, , , , M5, 40 L, STL, BLK, ZINC CR3, 8

SC-000256-00 SCR, PHH, PNH, TPG, PLASTITE, , , , M5, 45 L, STL, BLK, ZINC CR3, 8

SC-000283-00 SCR, PHH, PNH, MACH, , , , M5, 25 L, CLASS 4.6, BLK, ZINC, CR3 36

SC-000288-00 SCR, PHH, PHN, MACH, , , , M5, 20 L, STL CLASS 4.6, BLK, ZINC CR3, 18

SP-000183-00 WOOFER, 12", PAPER, FERRITE, , KSUB 2

WC-000493-00 WIRE HARNESS, , , , KSUB, , 1

WP-003310-00 CHASSIS ASSY, MAIN, KSUB, , UNIVERSAL SUPPLY 1

14.11 WP-003310-00, KSub BOP module assembly

Part Number Description Qty. Reference Comment

CH-000856-00 CHASSIS, MAIN, BUCKET, BOP-2CH, 1

CH-000880-00 CLAMP, TRANSISTOR, , BOP-2CH, 2
