QSC TouchMix-16 User Manual

135
1001108-01-F
2-Track Playback
Multi-Track Mode
TouchMix-30: Tracks 31/32
TouchMix-16: Tracks 21/22
TouchMix-8: Tracks 13/14
Stereo MP3 Mode
All models: From USB drive
DAW Mode*
TouchMix-30: DAW channels 31/32
Source
Main Outputs
L R
Cue
L R
Aux (Odd)
To Multi-Track
FX Sub-Groups (odd) * Sub-Groups (even) * Aux (Even)
Meter
Ch Fader
Pre
Post
From DCA Masters
Post Fdr
Pre Fdr
Pre Dyn
Pre all
Mute
Logic
Aux Send (Stereo)
RTA
Assign
Post Fdr
Pre Fdr
Pre Dyn
Pre all
SUM
SUM
Aux Send (Mono)
Mute
Mute
Mute
Cue
Balance
Balance
Gain
Gain
PEQ
Low Cut

QSC TouchMix-16 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
XLR out	8
DJ mixer	-
Audio input	4x XLR/TRS combo, 12x XLR, 2x TRS
Product color	Silver

Weight and Dimensions

Depth	291 mm
Width	360 mm
Height	58 mm
Weight	2980 g
