Chapter 22 Layer 3 Management Configuration
Switch only support Layer 2 forwarding, but can configure a Layer 3 management port for the
communication of all kinds of management protocols based on IP protocol.
22.1 Layer 3 Management Interface
22.1.1 Introduction to Layer 3 Management Interface
Only one layer 3 management interface can be created on switch. The Layer 3 interface is not
a physical interface but a virtual interface. Layer 3 interface is built on VLANs. The Layer 3
interface can contain one or more layer 2 ports which belong to the same VLAN, or contain no
layer 2 ports. At least one of the Layer 2 ports contained in Layer 3 interface should be in UP
state for Layer 3 interface in UP state, otherwise, Layer 3 interface will be in DOWN state. The
switch can use the IP addresses set in the layer 3 management interface to communicate with
the other devices via IP.
22.1.2 Layer 3 Interface Configuration Task List
Layer 3 Interface Configuration Task List:
1. Create Layer 3 management interface
2. Configure VLAN interface description
1. Create Layer 3 Management Interface
Command
Explanation
Global Mode
interface vlan <vlan-id>
no interface vlan <vlan-id>
Creates a management VLAN interface; the no command
deletes the VLAN interface created in the switch.
2. Configure VLAN interface description
Command
Explanation
VLAN Interface Mode
description <text>
no description
Configure the description information of VLAN interface.
The no command will cancel the description information
of VLAN interface.
