Step 1: Configure the IP addresses for the switch and start the HTTP server function on the
switch.
For configuring the IP address on the switch through out-of-band management, see the telnet
management chapter.
To enable the WEB configuration, users should type the CLI command IP http server in the
global mode as below:
Switch>enable
Switch#config
Switch(config)#ip http server
Step 2: Run HTTP protocol on the host.
Open the Web browser on the host and type the IP address of the switch, or run directly the
HTTP protocol on the Windows. For example, the IP address of the switch is “10.1.128.251”;
Run HTTP Protocol
When accessing a switch with IPv6 address, it is recommended to use the Firefox browser
with 1.5 or later version. For example, if the IPv6 address of the switch is 3ffe:506:1:2::3. Input
the IPv6 address of the switch is http://[3ffe:506:1:2::3] and the address should draw together
with the square brackets.
Step 3: Login to the switch.
Login to the Web configuration interface. Valid login name and password are required,
otherwise the switch will reject HTTP access. This is a method to protect the switch from
unauthorized access. As a result, when Telnet is enabled for configuring and managing the
switch, username and password for authorized Telnet users must be configured with the
following command: username <username> privilege <privilege> [password (0|7)
<password>]. To open the local authentication style with the following command:
authentication line web login local. Privilege option must exist and just is 15. Assume an
authorized user in the switch has a username of “admin”, and password of “admin”, the
