Standard IP ACL Mode
exit
Exits name-based standard IP
ACL configuration mode.
(4) Configuring an name-based extended IP access-list
a. Create an extended IP access-list basing on nomenclature
Command
Explanation
Global Mode
ip access-list extended <name>
no ip access-list extended <name>
Creates an extended IP access-
list basing on nomenclature; the
“no ip access-list extended
<name> “ command deletes the
name-based extended IP
access-list.
b. Specify multiple “permit” or “deny” rules
Command
Explanation
Extended IP ACL Mode
[no] {deny | permit} icmp {{<sIpAddr> <sMask>} | any-
source | {host-source <sIpAddr>}} {{<dIpAddr>
<dMask>} | any-destination | {host-destination
<dIpAddr>}} [<icmp-type> [<icmp-code>]] [precedence
<prec>] [tos <tos>][time-range<time-range-name>]
Creates an extended name-
based ICMP IP access rule; the
no form command deletes this
name-based extended IP
access rule.
[no] {deny | permit} igmp {{<sIpAddr> <sMask>} | any-
source | {host-source <sIpAddr>}} {{<dIpAddr>
<dMask>} | any-destination | {host-destination
<dIpAddr>}} [<igmp-type>] [precedence <prec>] [tos
<tos>][time-range<time-range-name>]
Creates an extended name-
based IGMP IP access rule; the
no form command deletes this
name-based extended IP
access rule.
[no] {deny | permit} tcp {{<sIpAddr> <sMask>} | any-
source | {host-source <sIpAddr>}} [s-port {<sPort> |
range <sPortMin> <sPortMax>}] {{<dIpAddr> <dMask>} |
any-destination | {host-destination <dIpAddr>}} [d-port
{<dPort> | range <dPortMin> <dPortMax>}]
[ack+fin+psh+rst+urg+syn] [precedence <prec>] [tos
<tos>][time-range<time-range-name>]
Creates an extended name-
based TCP IP access rule; the
no form command deletes this
name-based extended IP
access rule.
[no] {deny | permit} udp {{<sIpAddr> <sMask>} | any-
source | {host-source <sIpAddr>}} [s-port {<sPort> |
range <sPortMin> <sPortMax>}] {{<dIpAddr> <dMask>} |
any-destination | {host-destination <dIpAddr>}} [d-port
{<dPort> | range <dPortMin> <dPortMax>}] [precedence
Creates an extended name-
based UDP IP access rule; the
no form command deletes this
name-based extended IP
access rule.
