5
CONTROLS AND FUNCTIONS
AUX2 AUX3AUX1 PHONO
ON POWER OFF
12V
A
B
TRIG
OUT AUXPRE LEFTRIGHTLEFTRIGHT
ANALOGUE
INPUTS
Artera Pre
AC220-240V~50/60Hz 20W
FUSE T500mAL 250V
ANALOGUE
OUTPUTS
HEADPHONE JACK SOURCE REMOTE INPUT POWER/MUTE
LED
STANDBYVOLUME-VOLUME+
POWER
SWITCH
MAINS INPUT FUSE 12V TRIGGER
OUTPUT
BALANCED(XLR)
OUTPUTS
SINGLE-ENDED (RCA)
OUTPUTS
BALANCED(XLR)
INPUTS
SINGLE-ENDED (RCA)
INPUTS
PHONO GROUND
IMPORTANT
SAFETY INFORMATION
REMOTE
HANDSET
CONTROLS AND
FUNCTIONS
CONNECTIONS
SYSTEM
OPERATIONS
MENU
OPTIONS
SPECIFICATIONS CONTENTSINTRODUCTION
