2100-I & 3100-I FIREPLACE INSERT
Page 10
March 1999
INSTALLATION
INSTALLATION RECOMMENDATIONS
The Quadra-Fire 2100-I and 3100-I have met and surpassed the most stringent emissions
standards in the United States. The sophistication of the interior firebox design requires that a
proper draft be supplied by the chimney, therefore adherance to the following factors will enable
your stove to operate at its optimum capability:
REQUIRED
A minimum starter pipe reaching to the base of the existing chimney and an airtight face seal.
BETTER
Direct connection to the first flue liner in accordance with the requirements of the NFPA 211.
BEST
A complete relining of the chimney system with a six inch (6) diameter listed, stainless liner.
INSTALLATION IN CANADA
MASONRY, HEAT-EXCHANGER & FACTORY-BUILT
FIREPLACES
Whether installed in a masonry, heat-exchanger or factory-built fireplace, a
full chimney liner meeting ULC S635, CLASS III (stainless steel) must be
installed from the insert to the chimney top and securely attached to both.
Do not remove bricks or mortar from fireplace to accommodate insert.
The permanent metal warning label provided must be affixed to the back of
the fireplace stating that the fireplace may have been altered to accommo-
date the insert, and must be returned to original condition for use as a
conventional fireplace.
The face of the fireplace must be sealed to prevent room air passage into the
chimney cavity.
Circulating air chambers in factory-built fireplaces may not be blocked.
