2100-I & 3100-I FIREPLACE INSERT
Page 11 March 1999
GENERAL INSTALLATION PROCEDURE
Install liner, if required, for your chosen installation.
Attach metal warning plate to the back of the fireplace.
Set appliance on the hearth (See Hearth Requirements and Support Kits
information on page 9.)
Complete the vent connection required for your installation type.
Install optional blower, if purchased.
Install panel set. (See instructions on page 13)
Install trim. (See instructions on page 13)
Position unit into fireplace leaving width enough for fiberglass batt to be
inserted around face seal.
Work unit securely into the fireplace.
Install door handle. (See instructions on page 13)
Ensure that all labels are removed from glass prior to building first fire.
Ensure that gold plated surfaces are cleaned prior to building first fire.
(See instructions on page 22)
Read Operation Instructions found on pages 20-22.
UNPACKING AND USE OF LEVELING BOLTS
Your Quadra-Fire insert is secured to the pallet by means of two 1/2 x 6 bolts which
also serve as leveling bolts in the event that the hearth is higher than the fireplace floor. Follow
the procedures below for moving the insert from the pallet and use of the leveling bolts.
1. Remove 1/2 nuts from 1/2 x 6 bolts.
2. Bring 1/2 bolts up level to bottom of insert.
3. Position insert on hearth with rear of insert extending into fireplace opening.
4. Extend leveling bolts downward to level insert.
5. Make proper connection for desired venting technique.
INSTALLATION
