Quadra-Fire CAB50-C User Manual

11 09/207074-803C
Figure 11.1 - Top View w/ Top Vent Adapter (TPVNT-6) &
3 to 4 inch O󰀨set Adapter (811-0720)
Figure 11.2 - Side View w/ Top Vent Adapter (TPVNT-6) &
3 to 4 inch O󰀨set Adapter (811-0720)
9-7/8 in
(252mm)
9-7/8 in
(252mm)
3-1/8 in
(80mm)
3-1/8 in
(80mm)
15-1/8 in
(383mm)
15-1/8 in
(383mm)
16-3/4 in
(424mm)
16-3/4 in
(424mm)
