Quadra-Fire Expression 36 User Manual

53Quadra-Fire • Expression 36 (QV36A-FB) • 2062-900 Rev. S • 11/11
B. Vent Components Diagrams (continued)
Figure 16.4 DVP vent components
13-1/4 in.
(367 mm)
24-5/8 in.
(625 mm)
27-1/2 in.
(127 mm)
RF6M
Roof Flashing Multi-pak
31 in.
(787 mm)
24-5/8 in.
(625 mm)
13-1/4 in.
(367 mm)
RF12M
Roof Flashing Multi-pak
BEK
Trap Cap Brick Extension
13-3/4 in.
(349 mm)
5 in.
(127 mm)
13-3/4 in.
(349 mm)
Cap Shield
DRC-RADIUS
13-7/8 in.
(352 mm)
9-1/2 in.
(241 mm)
14 in.
(356 mm)
COOL-ADD
Cap Shield
11-5/8 in.
(295 mm)
5-3/4 in.
(146 mm)
7-1/8 in.
(181 mm)
12-1/8 in.
(308 mm)
DVP-TRAPFL
DVP-HSM-B
Extended Heat Shield
7-1/4 in.
(184 mm)
5-1/4 in.
(133 mm)
12-1/2 in.
(318 mm)
DVP-TVHW
VerticalTermination Cap (Highwind)
