Quality Espresso VISACREM V6 + - Installation and operation; 3.1 Before installing; 3.2 Installation

28
5
12
8
6
4
General description V6 +
2.
1 - Hot water outlet
2 - Front panel
4 - Cup Rail
3 - Display
1
2
3
7
9
10
11
5 - General Switch
6 - Steam arm protector
8 - Steam temperature sensor
7 - Steam arm
10 - Drainage tray
12 - Group head
11 - Filter-holder
TECHNICAL CHARACTERISTICS
Models
- DISPLAY
- GROUPTRONIC
No. of Groups
2Gr.
3Gr.
Width (B)
83 cm.
100 cm.
Height (A)
52 cm.
52 cm.
Depth (C)
57 cm.
57 cm.
Weight
72 kg.
86 kg.
Hydraulic Supply
3/8” Gas
3/8” Gas
Electrical Power
3,500 W.
4,600 W.
Boiler Capacity
13 L.
18 L.
a - On indicator
b - Boiler level indicator
c - Left steam button
a
b
d - Hot water button
c
d
e
f
g
h
i
e
f
g
h
i
e
f
g
h
i
j
k
e - Short coffee button
f - Two short coffees button
g - Long coffee button
h - Two long coffees button
i - Continuous coffee
button
j - Right steam button
k - Display
13
13 - USB port (located below the tray, pos.10)
9 - Grille for placing cups
14 - Group discharge
14
15
15 - Cup warming tray
A
B
C
2.2 Product selection buttons
2.1. General view
GB
