General sketch
2: Hot water outlet
3: Cold water inlet
4: temperature knob
5: Plug
Safety accessories
• Safety valve
The boiler is equipped with a safety valve
(overpressure valve).
It is normal for water to drip from the
pressure control hole when the boiler is
heating, the water in the tank expands
during heating and water will drip to
prevent overpressure.
If the water fails, the backow preventer
will prevent the water from owing back to
prevent dry burning.
The safety valve must be mounted on the cold water inlet (blue side).
The safety valve is factory set to 0.8MPa, you are not allowed to adjust this yourself.
The Safety Valve must be installed without frost to prevent freezing or blocking.
The safety valve must be installed downwards, with the pressure control hole
downwards and without blockage and kinks in the discharge stroke.
Incorrect installation will void the warranty.
