Quandify CubicSecure LTCS01 User Manual

TECHNICAL DATA
Area of use
Villa, terraced house, apartment
Environment
Indoor, (not waterproof)
Pipe connection
G20 Eurocone external thread (DN20)
Climate/Environment
5 °C ... 30 °C
Storage
-25 °C ... 55 °C
Wireless frequency
2.4 GHz, (802.11bgn)
Water temperature
Cold and hot water (0.1°C … 70°C)
Pressure
PN10
Maximum pressure (15min)
16 Bar
Waterflow during loss of water
pressure, 1 bar (Kvs)
4,6 m
3
/h
Maximum flow rate
3 000 l/h
Start flow rate
6 l/h
Micro-leakage detected
>0.5 bar pressure loss (approx. 0,01 l/h)
Medium sized leakage detected
>6 l/h for at least 45 minutes
Large leakage detected
>1500 l/h for at least 90 seconds
Weight
720 grams
Dimensions
71 mm height: 85 mm width, length 110 mm
Power supply
5VDC 2A Power supply, micro-USB cable (EU-plug), 1m cable
Average device power usage
~6 kWh/year (Wi-Fi on)
Default transmission resolution
1 hour
Valve open/close time
~10 seconds
Flow rate accuracy
Max ±3% error
Water temperature accuracy
Max ±2% error
Water pressure accuracy
Max ±10% error
Details are subject to change, check the latest version here.
The company is not liable for possible errors and/or misprints. 10 of 11
