CONNECT LED
Wi-Fi off and not configured.
Wi-Fi configured and connected to the
cloud.
The device is in hotspot mode for Wi-Fi
configuration using the app.
Ongoing pairing establishment between two
CubicSecures, one for cold water and one
for hot water.
Pairing completed between the hot and cold
water devices. The connection is made from
the cold water device which flashes
YELLOW/ BLUE.
Pairing completed between the hot and cold
water devices. The connection is made from
the hot water device which flashes
YELLOW/RED.
Hot/cold water pairing has been successful
and is completed.
No internet or cloud connection.
Check router firewall or redo
app setup.
LEAKAGE ALARMS
Detected by the valve being automatically closed daily to measure a
pressure drop above 0.5 bar for a maximum of 45 seconds.
The device alarms and shuts off the water after a continuous flow for
at least 45 minutes.
The device alarms and closes the valve after a continuous flow over
1500 l/h for at least 90 seconds.
Note that a larger leakage alarm will always override a smaller leakage detection. Above thresholds can
be modified using the mobile application.
Details are subject to change, check the latest version here.
The company is not liable for possible errors and/or misprints. 7 of 11
