Quanmax QBOX-207T User Manual

Chapter 2
12
QBOX-207T User’s Manual
Product Specifications
System Board
Intel
®
BayTrail SoC Processor, Atom™ E3845
Memory 1x DDR3L 1333 MT/S SO-DIMM up to 8 GB
I/O Panel
Front IOs
1x Power Button
1x HDD LED
1x Power LED
4x COM (COM 1~2 support RS-232/422/485, COM3~4 support RS-232)
3x Audio Jacks for Line-out/Line-In / Mic-In
Rear IOs
1x VGA
1x HDMI
2x RJ-45 Ports (GbE)
1x USB 3.0
4x USB 2.0
1x DC Jack
1x DIO
Storage
1x Option mSATA Socket
1x 2.5" SATA HDD / SSD
Wifi 802.11b/g/n
DIO 1x 8-bits programmable DIO (4-In, 4-Out)
Expansion Slot 2x mPCIe Sockets
OS Support Windows 7 , Window 8, Linux
Power Supply DC 12V
Temperature /
Humidity
Operating: -20°C to 70°C, 0%-95%, non-condensing
Storage: -20°C to 80°C, 0%-95%, non-condensing
Hardware Monitor
Voltages monitoring
Temperature monitoring
Watchdog Timer Programmable WDT to generate System reset event
TPM Option Intersil SLB9635 for TPM support
Dimensions 210 x 35 x 135mm (WxHxD)
Mounting
VESA mount
Certifications
CE, FCC Class A
Table 1 QBOX-207T product specifications
