Table 9 Advanced Menu – Super IO Configuration – Serial Port 4 Configuration
BIOS SETUP UTILITY
Main Advanced Boot Chipset Power Security Exit
Serial Port 4 Configuration
Serial Port [Enabled]
Device Settings IO=2E8h ; IRQ=7;
Change Settings [Auto]

: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save and Exit
ESC: Exit
Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc.
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=2E8h; IRQ=7;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F0h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E0h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
