System tour
Refer to the diagrams below to identify the components of the system.
Front Panel
Figure 1 Front Panel
Power Switch
The power button allows powering ON and OFF the system.
Power LED (Green)
The power LED will light when the PC is power-on.
HD LED (Red)
The hard disk LED blinks when data is being written into or read from the HDD.
Line Out
The stereo headphone jack is used to connect the system’s audio out signal to
amplified speakers or headphones.
MIC-IN
The microphone jack is designed to connect the microphone used for video
conferencing, voice narrations, or simple audio recordings.
Line-IN
The Line-in jack is designed to take input from a higher-powered sound source.
COM 1~4
D-Sub 9 pin connector
