QUANTA D51B-2U User Manual

ABOUT THE SYSTEM INTRODUCTION
1-4
Power supply
1+1 High efficiency redundant hot-plug PSU
(default with one PSU only; detailed PSU options please refer to "ordering
info" or "CCL")
Fan 4x dual rotor fans (7+1 redundant)
System management IPMI v2.0 Compliant, on board "KVM over IP" support
Operating environment
For QuantaGrid D51B-2U only:
 Operating temperature: 5°C to 40°C (41°F to 104°F)
 Non-operating temperature: -40°C to 65°C (-40°F to 149°F)
 Operating relative humidity: 20% to 85%RH.
 Non-operating relative humidity: 10% to 90%RH
For QuantaGrid D51BV-2U only:
 Operating temperature: 5°C to 35°C (41°F to 95°F)
 Non-operating temperature: -40°C to 65°C (-40°F to 149°F)
 Operating relative humidity: 20% to 85%RH.
 Non-operating relative humidity: 10% to 90%RH
Processor
Processor type:
Intel
® Xeon® processor E5-2600 v3 product family
Max. TDP support for QuantaGrid D51B-2U only: 145W
Max. TDP support for QuantaGrid D51BV-2U only: 135W
(145W with limited conditions)
Number of processors: 2
Internal Interconnect: 6.4 / 8.0 / 9.6 GT/s
Last Level Cache (LLC): Up to 45 MB
Chipset
Intel
® C610
Memory
Total slots: 24
Capacity: Up to 768GB RDIMM / Up to 1536GB LRDIMM
Memory type: 2133 MHz DDR4 RDIMM / LRDIMM
Memory size: 32GB, 16 GB, 8 GB RDIMM / 64GB, 32 GB LRDIMM
Networking
LOM:
 Option 1:
 Intel® I350 dual-port 1GbE
 Dedicated 1 GbE management port
 Option 2:
 Intel® X540 dual-port 10GbE BASE-T
 Dedicated 1 GbE management port
Optional NIC: (more options refer to the CCL)
Please refer to Compatible Component List (CCL) for more information
Storage controller
Onboard
Intel® C610:
 10x SATA 6Gb/s ports
 SATA RAID 0, 1, 10
Optional Controller: (more options refer to the CCL)
Please refer to Compatible Component List (CCL) for more information
Onboard Storage Support 2x SATADOM
Table 1.1: System Specifications (Continued)
