ABOUT THE SYSTEM A TOUR OF THE SYSTEM
1-8
1.3 A Tour of the System
System Overview
The server is available as a 2.5” (*only for QuantaGrid D51B-2U) and 3.5” HDD configura-
tion.
The 2.5” HDD configuration system overview (*only for QuantaGrid D51B-2U) is displayed
in the following image:
Figure 1-1. 2.5” System component overview (*only for QuantaGrid D51B-2U)
321 4
8910
5
54
6
6
11
7
