QUANTA D51B-2U User Manual

BMC FRONT PANEL USER INTERFACE
3-3
4PCIe Error
7: Bus Correctable Error
8: Bus Uncorrectable Error
A: Bus Fatal
5 Memory Event 0: Correctable Memory Error Logging Disabled
6
Temp_CPU0
Temp_CPU1
Temp_DIMM_AB
Temp_DIMM_CD
Temp_DIMM_EF
Temp_DIMM_GH
Temp_HDD_BP0*
Temp_HDD_BP1*
Temp_Ambient_PCI*
Temp_Inlet_MB*
Temp_PCI_Area*
Temp_PCI_Inlet1*
Temp_PCI_Inlet2*
Temp_PCH
Temp_Outlet
Temp_SSD0v
Temp_SSD1*
* It depends on physical plat-
form
Upper Critical Going High
Upper Non-Critical Going High
7
CPU0
CPU1
1: Thermal Trip
8 CPU_DIMM_VRHOT
0: CPU0 VR Hot
1: CPU1 VR Hot
2: DIMM_AB VR Hot
3: DIMM_CD VR Hot
4: DIMM_EF VR Hot
5: DIMM_GH VR Hot
9 DIMM_HOT
0: CPU0 Processor Hot
1: CPU1 Processor Hot
2: DIMM_AB Memory Hot
3: DIMM_CD Memory Hot
4: DIMM_EF Memory Hot
5: DIMM_GH Memory Hot
10 PCH Thermal Trip 1: State Asserted
Table 3.2: Status LED Activity (Continued)
NO.STATUS LED ACTIVITY DESCRIPTION
