Quantech 3070TSE User Manual

Name: Quantech 3070TSE
Brand: Quantech
Rating: 5 (1 reviews)

62 pages

To Next Page

To Previous Page

FORM QTC3-EG6 (1118)

QUANTECH

Unit Components

FIGURE 1 - QTC3 UNIT COMPONENTS

FAN DECK

MICROCHANNNEL

COILS

COIL

HEADERS

CONTROL AND

POWER

PANELS

COMPRESSORS

BRAZED PLATE

EVAPORATOR

FORMED STEEL BASE

RAILS

HYDRO-KIT

PUMPS AND

MOTORS

(OPTIONAL)

LD18426
