FORM QTC3-EG6 (1118)
QUANTECH
41
PUMP
MODEL
HORSE
POWER
RPM
PUMP ELECTRICAL DATA
208V-3-60HZ 230V-3-60HZ 380V-3-60HZ 460V-3-60HZ 575V-3-60HZ
FLA LRA FLA LRA FLA LRA FLA LRA FLA LRA
A
5 3600 15.4 4.6 13 3.9 7.9 2.4 6.5 2 5.2 1.6
B
7.5 3600 23.2 7 18.4 5.5 11.1 3.3 9.2 2.8 7.4 2.2
C
10 3600 28.3 8.5 24 7.2 15.1 4.5 12 3.6 9.6 2.9
D
3 1800 9.5 2.9 8 2.4 4.7 1.4 4 1.2 3.2 1
E
15 3600 43 12.9 36.4 10.9 22 6.6 18.2 5.5 14.6 4.4
F
7.5 3600 23.2 7 18.4 5.5 11.1 3.3 9.2 2.8 7.4 2.2
G
10 3600 28.3 8.5 24 7.2 15.1 4.5 12 3.6 9.6 2.9
H
15 3600 43 12.9 36.4 10.9 22 6.6 18.2 5.5 14.6 4.4
I
5 1800 15.4 4.6 13 3.9 7.9 2.4 6.5 2 5.2 1.6
J
15 3600 43 12.9 36.4 10.9 22 6.6 18.2 5.5 14.6 4.4
K
20 3600 54 16.2 45 13.5 28.7 8.6 22.5 6.8 18 5.4
L
3 1800 9.5 2.9 8 2.4 4.7 1.4 4 1.2 3.2 1
M
10 3600 23.2 7 18.4 5.5 11.1 3.3 9.2 2.8 7.4 2.2
N
20 3600 54 16.2 45 13.5 28.7 8.6 22.5 6.8 18 5.4
P
5 1800 15.4 4.6 13 3.9 7.9 2.4 6.5 2 5.2 1.6
R
15 3600 43 12.9 36.4 10.9 22 6.6 18.2 5.5 14.6 4.4
S
3 3600 9.5 2.9 8 2.4 4.7 1.4 4 1.2 3.2 1
T
5 3600 15.4 4.6 13 3.9 7.9 2.4 6.5 2 5.2 1.6
U
10 3600 28.3 8.5 24 7.2 15.1 4.5 12 3.6 9.6 2.9
V
10 1800 28.3 8.5 24 7.2 15.1 4.5 12 3.6 9.6 2.9
Variable Speed Pump Electrical Data
CONTROL TRANSFORMER LOAD
VOLT
KVA
2 3
208
9.6 14.4
230
8.7 13.0
380
5.3 7.9
460
4.3 6.5
575
3.5 5.2
