Quantech QTC3 Series User Manual

FORM QTC3-EG6 (1118)
QUANTECH
23
REFRIGERANT R-410A
QTC3
REFRIGERANT R-410A
QTC3
STANDARD EFFICIENCY UNITS HIGH EFFICIENCY UNITS
070TSE 075TSE 085TSE 095TSE 110TSE 125TSE 140TSE 160TSE 055THE 060THE 079THE 090THE 100THE 120THE 129THE 150THE 170THE 205THE 225THE
NOMINAL RATINGS NOMINAL RATINGS
TONS 70.8 77.6 81.6 95.3 115.7 125.7 142.6 166.7
TONS
56.8 62.1 77.9 85.5 98.0 117.8 126.1 144.0 171.9 194.5 220.6
KW 77.5 86.3 93.0 111.5 134.6 142.6 165.0 192.1
KW
64.4 71.9 90.9 83.6 106.1 122.0 149.6 153.0 194.2 210.9 240.0
EER 10.4 10.0 9.8 9.7 9.8 9.7 9.7 9.7
EER
10.6 10.4 10.3 11.0 10.1 10.3 10.1 10.2 9.8 10.1 10.2
IPLV 16.1 15.6 15.8 14.5 15.0 15.8 15.8 15.6
IPLV
15.6 15.6 16.1 16.1 15.7 15.7 16.0 15.5 15.6 16.1 15.2
GENERAL UNIT DATA GENERAL UNIT DATA
Length, Inches 116.1 116.1 116.1 142.7 142.7 187.7 187.7 232.7
Length, Inches
100.2 100.2 100.2 142.7 142.7 187.7 187.7 232.7 232.7 274.4 274.4
Width, Inches 88 88 88 88 88 88 88 88
Width, Inches
88.0 88.0 88.0 88 88 88 88 88 88 88.3 88.3
Height, Inches 94.2 94.2 94.2 94.2 94 94.2 94.2 94.2
Height, Inches
94.2 94.2 94.2 94.2 94.2 94.2 94.2 94.2 94.2 94.2 94.2
Number of Refrigerant
Circuits
2 2 2 2 2 2 2 2
Number of Refrigerant
Circuits
2 2 2 2 2 2 2 2 2 2 2
REFRIGERANT CHARGE, OPERATING REFRIGERANT CHARGE, OPERATING
R-410A, Circuit -1/Circuit -2, lbs 43/43 47/44 57/57 55/58 54/62 75/71 75/70 90/87
R-410A, Circuit -1/Circuit
-2, lbs
43/43 43/43 44/44 59/55 45/65 75/71 76/76 90/82 94/92 95/95 100/100
Oil Charge, Circuit -1/Circuit -2,
gallons
2.58/2.58 3.28/2.58 3.28/2.76 3.28/3.33 3.33/3.33 4.99/2.76 4.99/3.33 4.99/4.99
Oil Charge, Circuit.-1/
Circuit -2, gallons
2.58/2.58 2.89/2.58 2.58/2.58 2.76/2.76 2.76/2.76 3.33/3.33 4.20/2.80 4.99/3.33 4.99/4.99 4.2/4.2 4.99/4.99
Shipping Weight, lbs 3578 3898 4168 4791 5183 6148 6414 7734
Shipping Weight, lbs
3508 3704 4213 4718 4953 5869 6380 7344 7882 9205 9690
Operating Weight, lbs 3623 3954 4241 4864 5293 6232 6524 7818
Operating Weigh, lbs
3552 3748 4295 4791 5026 5942 6488 7428 8001 9333 9821
COMPRESSORS, SCROLL TYPE COMPRESSORS, SCROLL TYPE
Compressors per circuit 3/3 3/3 3/3 3/2 3/2 3/3 3/2 3/3
Compressors per circuit
2/2 3/2 3/3 3/3 3/2 2/2 3/2 3/2 3/3 3/3 3/3
Compressors per unit 6 6 6 5 4 6 5 6
Compressors per unit
4 5 6 6 5 4 5 5 6 6 6
NOMINAL TONS PER COMPRESSOR NOMINAL TONS PER COMPRESSOR
Circuit 1 13 15 15 15 32 32 32 32
Circuit 1
15 13 15 15 15 32 25 32 32 35 40
Circuit 2 13 13 15 32 32 15 32 32
Circuit 2
15 15 13 15 32 32 32 32 32 35 40
CONDENSER CONDENSER
Total Face Area ft
2
106.9 106.9 106.9 133.6 160.3 213.8 213.8 267.2
Total Face Area ft
2
106.9 106.9 106.9 160.3 160.3 213.8 213.8 267.2 267.2 320.7 320
Number of Rows 1 1 1 1 1 1 1 1
Number of Rows
1 1 1 1 1 1 1 1 1 1 1
Fins per Inch 20 20 20 20 20 20 20 20
Fins per Inch
20 20 20 20 20 20 20 20 20 20 20
CONDENSER FANS, LOW SOUND CONDENSER FANS, LOW SOUND
Number of Fans, Circuit.-1/Circuit.-2 2/2 2/2 2/2 3/2 3/3 4/4 4/4 5/5
Number of Fans, Circuit.-1/
Circuit.-2
2/2 2/2 2/2 3/3 4/2 4/4 4/4 6/4 5/5 6/6 6/6
Fan HP 2 2 2 2 2 2 2 2
Fan HP
2 2 2 2 2 2 2 2 2 2 2
Fan RPM 1160 1160 1160 1160 1160 1160 1160 1160
Fan RPM
1160 1160 1160 1160 1160 1160 1160 1160 1160 1160 1160
Total Chiller CFM 62400 62400 62400 78000 93600 124800 124800 156000
Total Chiller CFM
62400 62400 62400 93600 93600 124800 124800 156000 156000 187200 187200
EVAPORATOR EVAPORATOR
Water Volume, Gallons 5.4 6.7 8.8 8.8 13.2 10.0 13.2 10.0
Water Volume, Gallons
5.4 5.4 10 8.8 8.8 8.8 13.2 10.0 14.3 12.6 14.3
Maximum Water Side Pressure, PSIG 150 150 150 150 150 150 150 150
Maximum Water Side
Pressure, PSIG
150 150 150 150 150 150 150 150 150 150 150
Maximum Refrigerant Side Pressure,
PSIG
450 450 450 450 450 450 450 450
Maximum Refrigerant
Side Pressure, PSIG
450 450 450 450 450 450 450 450 450 450 450
Minimum Chiller Water Flow Rate,
GPM
60 100 100 100 150 115 150 150
Minimum Chiller Water
Flow Rate, GPM
60 60 138 100 100 100 138 150 150 230 220
Maximum Chiller Water Flow Rate,
GPM
325 350 400 400 625 625 625 625
Maximum Chiller Water
Flow Rate, GPM
325 325 525 400 400 400 525 525 625 625 625
Water Connections Size, Inches 3 3 3 3 3 4* 4* 4*
Water Connections
Size, Inches
3 3 3 3 3 4* 4* 4* 4* 5" 5"
* Side extension kit (standard), evaporator nozzle remains 3”. * Side extension kit (standard), evaporator nozzle remains 3”.
Physical Data and Nominal Ratings (Cont'd)
