Quantech QTC3 Series User Manual

FORM QTC3-EG6 (1118)
QUANTECH
47
QTC3 VOLT HZ MCA
MIN N/F
DISC
SW
MIN DUAL
ELEM FUSE
& MIN CB
MAX DUAL
ELEM FUSE
MAX CB
SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA
120T
208 60 537 600 600 600 106.2 523 106.2 523 4 7.6 44
230 60 532 600 600 600 106.2 578 106.2 578 4 7.4 37
380 60 322 400 350 350 64.3 355 64.3 355 4 4.5 23.1
460 60 269 400 300 300 53.1 290 53.1 290 4 4 19
575 60 204 250 225 225 42.5 255 42.5 255 4 2.9 15.3
125T
208 60 579 800 600 600 57.7 284 57.7 284 57.7 284 4 7.6 44
230 60 577 800 600 600 57.7 330 57.7 330 57.7 330 4 7.4 37
380 60 338 400 400 400 30.9 192 30.9 192 30.9 192 4 4.5 23.1
460 60 285 400 300 300 26.9 180 26.9 180 26.9 180 4 4 19
575 60 226 250 250 250 21.5 132 21.5 132 21.5 132 4 2.9 15.3
129T
208 60 555 800 600 600 106.2 523 106.2 523 106.2 523 4 7.6 44
230 60 553 800 600 600 106.2 528 106.2 528 106.2 528 4 7.4 37
380 60 329 400 350 350 64.3 355 64.3 355 64.3 355 4 4.5 23.1
460 60 274 400 300 300 53.1 290 53.1 290 53.1 290 4 4 19
575 60 217 400 250 250 42.5 255 42.5 255 42.5 255 4 2.9 15.3
140T
208 60 618 800 700 700 106.2 523 106.2 523 4 7.6 44
230 60 617 800 700 700 106.2 578 106.2 578 4 7.4 37
380 60 374 400 400 400 64.3 355 64.3 355 4 4.5 23.1
460 60 311 400 350 350 53.1 290 53.1 290 4 4 19
575 60 246 400 300 300 42.5 255 42.5 255 4 2.9 15.3
150T
208 60 634 800 700 700 106.2 523 106.2 523 4 7.6 44
230 60 632 800 700 700 106.2 578 106.2 578 4 7.4 37
380 60 383 400 400 400 64.3 355 64.3 355 4 4.5 23.1
460 60 319 400 350 350 53.1 290 53.1 290 4 4 19
575 60 252 400 300 300 42.5 255 42.5 255 4 2.9 15.3
160T
208 60 740 800 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 800 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 400 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
170T
208 60 740 800 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 800 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 400 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
205T
208 60 734 1000 800 800 102.8 574 102.8 574 102.8 574 6 7.6 44
230 60 731 1000 800 800 102.8 635 102.8 635 102.8 635 6 7.4 37
380 60 443 600 500 500 62.2 355 62.2 355 62.2 355 6 4.5 23.1
460 60 369 600 400 400 51.4 280 51.4 280 51.4 280 6 4 19
575 60 292 400 300 300 41.1 225 41.1 225 41.1 225 6 2.9 15.3
225T
208 60 959 1200 1000 1000 138.8 943 138.8 943 138.8 943 6 7.6 44
230 60 956 1200 1000 1000 138.8 943 138.8 943 138.8 943 6 7.4 37
380 60 599 800 600 600 87.2 564 87.2 564 87.2 564 6 4.5 23.1
460 60 504 600 600 600 73 408 73 408 73 408 6 4 19
575 60 359 600 400 400 51.9 375 51.9 375 51.9 375 6 2.9 15.3
Electrical Data Without Pumps (Cont'd)
NOTES: 1. Reference PIN 59 on the unit panel for pump models.
2. Use this table along with Pump Electrical Data on page 41 to determine electrical data of the unit plus the pump.
3. Does not include the Control Transformer on page 41.
