980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation Rev. A1
Page 29 Feb 14, 2013
Test ID
% of full buffer (2GB)
Resulting/Required buffer size
7-36 – High Bitrate Audio
41.492
743MB
7-37 – One Bit Audio
4.48
88MB
7-38 – 3D Video Format Timing
4.322
77MB
7-39 – 4K x 2K Video Format Timing
4.322
77MB
7-40 – Extended Colorimetry Transmission
4.322
77MB
p-scope> pcap mode all // captures all data types (video, data islands)
Pre-Capture Filter set to: No filtering
p-scope> pcap trig vsync 0 // sets the capture trigger to vsync
cap_trig: trigger basic type=0x1 position=0%
p-scope> pcap start // 980 initiates capture
Waiting for the capture trigger event to occur…
Vsync Asserted
INFO: Capture Trigger condition is satisfied
END: pcap_capture_start
Capture complete
Capturing data…
END: Capture complete, capture size 116.17MB [circular], buffer size 116.17MB
Post-Capture Processing
p-scope> pcap timing // generating field timing information.
END: pcap_info info request type=112 complete
p-scope> pcap decode // decode the captured data.
END: decode request complete
Indexing the decode data…
p-scope> pcap index // indexing the decoded data.
Analyzing the captured test data.
p-scope> exec perl /qd/hdmi_cts/HDMI_CTS.pl –f /home/qd –v 4 –t 7_39 –r 2
// run the 7-39 compliance test on the captured files.
Analyzing the captured test data.
Test 7-39 Iter 01 -> Pass
