980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation Rev. A1
Page 30 Feb 14, 2013
4 Sample Test Results file
This section provides an example of a test results file.
4.1 Sample Test Results file
The results for a test can be found in the file HDMI_CTS_OUTPUT.log. In the /home/qd directory. An example of
this file for the 7-17 test is shown below.
--------------------------------------------------
[2013-02-13 09:48:51]
[7_17 BASIC PROTOCOL]
7_17_1:Control Period Encoding:Expected Values 0x354, 0x0ab, 0x154, 0x2ab
7_17_2:Data Island(DI) Guard Band:Exp Vals Ch0 0x28e, 0x271, 0x163, 0x2c3, Ch1-Ch2
0x133
7_17_3:TERC4 Codes
7_17_4:Video Guard Band:Exp Vals 0x2cc, 0x133, 0x2cc
7_17_5:Legal Video Data codes
7_17_6:Control period 12 pix before transition to next character
7_17_7:Valid video and data preamble of 8pix
7_17_8:Control period prior to the preamble should not have Data Island preamble
control code
7_17_9:Illegal preamble
7_17_10:Leading and Trailing guard Band(GB)
7_17_11:First Chr following the Leading GB should not have TERC4 ch0, bit 3==1
7_17_12:Any other Chr prior to trailing GB should have TERC4 ch0, bit 3==1
7_17_13:DI Length and count
7_17_14:BCH Parity check
7_17_15:ENC_EN code is detected
----------------ERROR and INFO log----------------
----------------------RESULT----------------------
Test 7_17 Passed
HDMI 1.4 CTS summary
Total tests executed : 1
Total tests passed : 1
Total tests failed : 0
