Quantum DXi4700

Chapter 5: Home Page
Current Activity
Quantum DXi4700 User’s Guide 120
Current Activity Information Description
Inline The inline data flow throughput (in MB/s). Inline data
flow includes deduplicated and non-deduplicated
backup data as well as received OST data. Click to
view detailed statistics for inline performance in
Advanced Reporting.
Replication Throttle The system replication throttle currently in effect (in
KB/s or MB/s). When a constant throttle is enabled, the
DXi limits the amount of data it sends during source
replication so that it does not exceed the specified
bandwidth. Click to enable or disable system throttling
(see Replication Configuration on page 253).
Ethernet The amount of data received (In) and sent (Out) by all
Ethernet ports (in MB/s). Click to view details statistics
for Ethernet performance in Advanced Reporting.
Fibre Channel
(VTL and Multi-Protocol configuration only)
The amount of data received (In) and sent (Out) by all
Fibre Channel ports (in MB/s). Click to view details
statistics for Fibre Channel performance in Advanced
Reporting.
Accent Accent statistics include NAS Application Specific
(RMAN) and OST Accent throughput activity for the
previous minute.
OST activity is included only if Accent is selected for
OST.
Inline - The inline data flow throughput (in MB/s). Inline
data flow represents the original, native size of the data
protected by the DXi.
Ethernet In - The amount of data received by all
Ethernet ports (in MB/s). This amount represents the
reduced size of the data protected by the DXi (after
deduplication and compression on the media servers).
Bandwidth Reduction - The percentage by which
network bandwidth utilization was reduced by Accent
and/or RMAN.
OST Service
(NAS and Multi-Protocol configuration only)
The status of the OST service. OST settings can be
configured in Ready, Stopped, or Verifying state. The
OST server is available for backup only in Ready state.
