Chapter 9: Configuration
System
Quantum DXi4700 User’s Guide 290
To send a test SNMP trap, select a destination in the list and click Send. If the destination does not receive
the SNMP trap, make sure that the destination IP address is correct (see Editing a Destination on
page 283). Also make sure that the community information is correct (see Community on page 284).
System
The System page allows you to configure system settings for the DXi4700, including network settings,
system date and time, and security settings.
To access the System page, click the Configuration menu, and then click the System tab.
The System page contains the following tabs:
l Network below
l Date & Time on page 302
l Security on page 304
l Manage Users on page 319
l Client Plug-Ins on page 322
l App Environment on page 323
l Redirect Logging on page 333
l FC Initiators and Targets on page 334
Network
The Network page allows you to view and change network configuration information for the DXi4700. The
DXi4700 uses this information to connect to the network.
Network configuration information is entered during initial setup DXi4700. You should consult your network
administrator before making any changes to the network settings.
Caution: Changing the network configuration requires a system reboot to allow all system services to
function correctly. Changing the network configuration requires a system reboot immediately after the
changes are applied.
To access the Network page, on the System page, click the Network tab.
Configuring the Network
Using the Network page, each physical Ethernet port in the DXi can be configured as a separate device. In
addition, you can create bonded devices (logical ports) consisting of two or more physical ports of the same
