QXS-484 12G System Specifications 37
NOTE: Figure 34 displays the front of the drawer on the left side of the illustration. The back of the
drawer is on the right side of the illustration.
Figure 34 5U84 RAID or Expansion Chassis Drive Slots
2
1
3
4
0/42
2/44
1/43
3/45
4/46
5/47
6/48
7/49
8/50
9/51
10/52
11/53
12/54
13/55
14/56
15/57
16/58
23/65
18/60
19/61
20/62
21/63
22/64
41/83
17/59
25/67
26/68
27/69
28/70
29/71
30/72
31/73
24/66
37/79
38/80
35/77
39/81
33/75
34/76
36/78
40/82
32/74
1
Drawer 0/1 Front
2
Drawer 0/1 Left Side
3
Drawer 0/1 Rear (slides into chassis)
4
Drawer 0/1 Right Side
