QubEV QUBEV-UG-02 Installation and Operation Manual
Page 6 of 15 November 2020
Electrical Specification
EVON0010 EVON0040
Description
QUBEV Universal Socket EV Charging
Unit
QUBEV Universal Socket EV Charging
Unit
Rated Output Up to 7.2kW (32A)
Rated Current Up to 32A max
AC Overload Protection N/A 1x C40A MCB
AC & DC Fault Protection N/A Type B RCD
Charging Current Variable - 6A, 20A, 25A & 32A
Input Voltage 230V AC/50Hz (Single Phase)
Incoming Cable Terminals 3 x 16mm terminals
Overcurrent Protection Recommended 40A
Charging Socket IEC 62196 (Type 2)
Charge Protocol Mode 3
Certifications and Compliances
This product has been designed and built in accordance with the following standards and
legislation:
EV Charging Compliance EN 61851-1:2001, EN 61851-21:2002, EN 61851-22:2002
Wiring Regulations BS 7671
IET EV Regulations, Glow Wire Testing IEC 60695-2-13
EMC Compliance 2014/30/EU, EN 61000-6-3:2007, EN 61000-6-2:2005
Safety Compliance EN 60950-1:2006, EN 60950-22:2006
Low Voltage Directive (LVD) 2014/35/EU
Metal Enclosure (where supplied) EN 55014-1: 2006+A1: 2009+A2: 2011, EN 55014-2: 2016
EN 61000-3-2:2014, EN 61000-3-3:2014
EN 60335-1: 2012+A11: 2014
Switchgear (where supplied) EN 61543: 1995/+A11: 2003/+A12: 2005/+A2: 2006
EN 61008-1: 2010+A1+A2, EN 61008-1: 2012+A1+A2+All+A12
EN 61008-2-1:1990, EN 61008-2-1:1994+A11
EN 62423:2009, EN 62423:2012
Unpacking
The content of the package depends on any options or accessories that may have been selected.
IMPORTANT: Make sure all packaging is disposed of responsibly and in accordance with the
current regulations in your region.
Typical Contents
x 1 x EV Charging Device.
x 1 x Installation and Operators Manual.
x 1 x Fixing Template.
x 4 x Wall Plugs.
x 4 x Washers.
x 4 x Fixings.
Installation
QUBEV-UG-02 Installation and Operation Manual QubEV
September 2020 Page 7 of 15
Typical Options
x EV charging cables (Type 1 to Type 2 or Type 2 to Type 2)
x Charge point signage
Installation
WARNING: Electrical Power
Make sure electrical power is isolated BEFORE starting this procedure.
x Turn power OFF at SOURCE.
IMPORTANT: Installers and End Users must read and understand the content of
this manual before installation and/or use of the product.
Installation must only be performed by someone who is properly qualified and competent to do
so in accordance with the current legislation in force in the geographical location of the
installation.
x Advice provided in this manual does NOT override any legislation.
x If the advice in this manual is not understood, contact the distributor for further advice
and/or training BEFORE attempting installation/operation of the equipment.
x The manufacturer/distributor cannot accept any responsibility for improper installation or
any problems arising from improper installation.
NOTE: Damage to the equipment, connected systems or to property caused by improper
installation are the responsibility of the installer.
Before Installation
1. Establish a suitable site location for the unit that is both secure and environmentally safe.
2. Make sure the location meets current legislation (if applicable).
3. Make sure there is a suitable mains power supply available at the installation site.
4. Make sure the unit model is correct and matches the order.
5. Make sure the unit and any accessories do not appear to have been damaged in transit.
x Further detail is provided in the Installation procedure.
6. Make sure the supplied fixings are suitable for the mounting location. If not suitable,
alternatives must be obtained locally before proceeding with the installation.
