ZK105M User Manual M
7
FCC Certification
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .This equipment should be installed and operated with minimum distance
20cm between the radiator& your body.
GPS Specifications
No. Item Parameters
1 GPS Type u-Blox M8130 KT GPS Receiver
Sensitivity22
Tracking & Navigation: -162dBm
Reacquisition: -160dBm
Coldstart: -147dBm
Warm start: -148dBm
Hot start:-155dBm
3 Position Accuracy (CEP)
GPS without SBAS: <2.5m
GPS with SBAS: <2.0m
44 TTFF (Open Sky)
Cold start: 30s average
Warm start: <28s
Hot start: <1s
BLE Parameters
Item No. Parameters
1
Antenna
Internal only
22
Chipset
BLUENRG-132
33
Frequency
2.4GHz RF Transceiver compatible with Bluetooth
low energy(BLE)
44 Sensitivity Excellent receiver sensitivity: -88dBm
5 Max out RF power up to 10dBm
NFC Parameters
Item No. Parameters
11
Antenna
Internal only
22
Chipset
PN7150
33
Frequency
13.56MHz full NFC controller solution
