Quectel 5G Module Series - Page 40

5G Module Series
5G-REDCAP_EVB_User_Guide 39 /
46
10
CBL_PWR_N
133
Connected directly to CBL_PWR_N of the
module
J1207
Pin No.
Pin Name
Module Pin No.
Description
1
GND
0–12, 23, 26, 33, 35,
38, 40, 50, 52, 54,
56–60, 62, 78, 109,
115, 125, 126, 135,
137, 140, 141, 143,
149, 151, 163, 169–204
Ground
2
DBG_RXD
13
Connected directly to DBG_RXD of the module
3
DBG_TXD
14
Connected directly to DBG_TXD of the module
J1203
Pin No.
Pin Name
Module Pin No.
Description
1
3V3
NA
3.3 V power
2
NC
NA
NC
3
1V8
NA
1.8 V power
J0104
Pin No.
Pin Name
Module Pin No.
Description
1
SPI_CS
41
Connected directly to SPI_CS of the module
2
SPI_MOSI
42
Connected directly to SPI_MOSI of the module
J0105
Pin No.
Pin Name
Module Pin No.
Description
1
SPI_MISO
43
Connected directly to SPI_MISO of the module
2
SPI_CLK
44
Connected directly to SPI_CLK of the module
J0102
Pin No.
Pin Name
Module Pin No.
Description
1
VDD_EXT
7
Connected directly to VDD_EXT of the module
2
USB_BOOT
22
Connected directly to USB_BOOT of the module
