Table 20: Pin Definition of Test Points
J1204
Pin No.
Pin Name
Module Pin No.
Description
1
GND
0–12, 23, 26, 33, 35,
38, 40, 50, 52, 54,
56–60, 62, 78, 109,
115, 125, 126, 135,
137, 140, 141, 143,
149, 151, 163, 169–204
Ground
2
PWRKEY
25
Connected directly to PWRKEY of the module
3
POWER_EN
NA
DTR control module power
4
RESET_N
24
Connected directly to RESET_N of the module
5
RI
68
Connected directly to MAIN_RI of the module
6
AP_READY
NA
Application processor ready
7
DCD
69
Connected directly to MAIN_DCD of the module
8
MAIN_RTS
71
Connected directly to MAIN_RTS of the module
9
MAIN_CTS
70
Connected directly to MAIN_CTS of the module
10
MAIN_DTR
72
Connected directly to MAIN_DTR of the module
J1202
Pin No.
Pin Name
Module Pin No.
Description
1
GND
0–12, 23, 26, 33, 35,
38, 40, 50, 52, 54,
56–60, 62, 78, 109,
115, 125, 126, 135,
137, 140, 141, 143,
149, 151, 163, 169–204
Ground
2
WAKEUP_IN
1
Connected directly to WAKEUP_IN of the
module
3
0V9
NA
0.9 V power
4
W_DISABLE#
NA
Airplane mode control
5
1V65
NA
1.65 V power
6
ADC0
49
Connected directly to ADC0 of the module
7
3V
NA
3 V power
8
ADC1
48
Connected directly to ADC1 of the module
9
VRTC
NA
NC
