Page #11 background imageLoading...
Page #11 background image
NB-IoT Module Series
BC95 Hardware Design
BC95_Hardware_Design Confidential / Released 10 / 51
2.2. Key Features
The following table describes the detailed features of BC95 module.
Table 2: BC95 Key Features
Feature
Details
Power Supply
Supply voltage: 3.1V ~ 4.2V
Typical supply voltage: 3.6V
Power Saving Mode
Maximum power consumption in PSM: 5uA
Transmitting Power
23dBm±2dB
Temperature Range
Operation temperature range: -30°C ~ +75°C
1)
Extended temperature range: -40°C ~ +85°C
2)
USIM Interface
Only support USIM card: 3.0V
UART Interfaces
Main port:
Used for AT command communication and data transmission, and
the baud rate is 9600bps
Main port can also be used for firmware upgrading, and the baud rate
is 115200bps
Debug port:
Debug port is used for debugging
Only support 921600bps baud rate
Internet Protocol Features
Support IPV4/IPV6*/UDP/CoAP
SMS*
Text and PDU mode
Point to point MO and MT
Data Transmission Feature
Single tone with 15kHz subcarrier: 24kbps (DL), 15.625kbps (UL)
AT Commands
Compliant with 3GPP TS 27.005, 27.007 and Quectel enhanced AT
commands
Physical Characteristics
Size: (19.9±0.15)mm × (23.6±0.15)mm × (2.2±0.2mm)
Weight: 1.8g±0.2g
Firmware Upgrade
Firmware upgrade via main port or DFOTA*
Antenna Interface
Connected to antenna pad with 50 Ohm impedance control
RoHS
All hardware components are fully compliant with EU RoHS directive
